Creating a GitHub Action for a Docker Image

What’s are GitHub Actions anyway?

Actions are one of the the smallest executable steps of a job, or you can say a job is composed of steps which can be actions or commands. You can create GitHub Actions based on docker images. More details.

Creating a Github Action for an existing Dockerfile

Mainly three files are required, Dockerfile, and actions.yml.

Let’s start with creating a Dockerfile for our action, I’ll use my Android CI Dockerfile. It’s a simple Dockerfile, which includes all Android build-related tools, recent SDKs, Java, etc.

The Dockerfile for action uses the existing Docker image and extends it to include `entrypoint` script. The idea for the script is basically to pass the input from a step in workflow to runtime of the Docker in the Github environment.

Dockerfile

# Container image that runs your code
FROM code0987/android-ci:latest
# Copy your code to the filesystem path `/` of the container
COPY entrypoint.sh /
# Grant executable permission to entrypoint file
RUN [“chmod”, “+x”, “/entrypoint.sh”]
# Code file to execute when the docker container starts up (`entrypoint.sh`)
ENTRYPOINT [“/entrypoint.sh”]

entrypoint.sh

This script runs all the input passed from GitHub Workflow, as a set of commands in non-interactive `sh` spawned inside Docker runtime.

#!/bin/sh
set -eu
sh -c "$*"

Now let’s define the action metadata so that GitHub can recognize this action. The specifics for Dockerfile based actions are, defining -

runs:
 using: 'docker'
 image: 'Dockerfile'
 args: …

actions.yml

name: 'Hello World'
description: 'Greet someone and record the time'runs:
  using: 'docker'
  image: 'Dockerfile'

Using above action in a GitHub Workflow

name: Android CI
on: [push]
jobs:
  android-ci:
    runs-on: ubuntu-latest
    steps:
    - uses: actions/checkout@v1
    - name: "Android CI Github Action"
      uses: code0987/android-ci-github-action@master
      with:
        args: |
          chmod 755 gradlew
          gradlew check

---

References

GitHub repo for action used as example, android-ci-github-action.

https://help.github.com/en/actions/building-actions/creating-a-docker-container-action
